SECTION 8 - HANDLES, LATCHES & CATCHES
WDS
✆
0845 606 66 77
•
www.wdsltd.co.uk•
sales@wdsltd.co.uk8-54
WDS
www.wdsltd.co.ukCollapsible Tray
Handle with Pull
Back Spring
WDS 8539
MATERIAL
-
Aluminium
Pullback spring returns handle to
closed position
L
L1 L2 L3 L4 C C1 T
T1 T2
Load Capacity
(kg)
(g)
Colour
WDS No.
129 91 109 69 48 118 79 20.5 4.5 2
50
197
black 8539-211
129 91 109 69 48 118 79 20.5 4.5 2
50
197
grey
8539-212
129 91 109 69 48 118 79 20.5 4.5 2
50
197
white 8539-213
/
/
/
/
&
&
7R VXLW 0 F VLQN VFUHZV
/
7
7
7
Al
A
B
C
C1
C2
C3
C4
D
H
H1
(g)
WDS No.
162 108 138.8 86.5
42
94.5 147.5 5.2
10
1.2
390
8661-202
176 126 151.8 103.8 50
112 161.5 5.2
10
1.2
480
8661-203
Recessed Handle
- Spring Loaded
Return, 10
Mounting Holes
WDS 8661
MATERIAL
-
Zinc Plated Steel with
Black PVC Grip
$
%
'
&
&
&
&
&
+
+
$
%
'
&
&
&
&
&
+
+
ZP
A
B
C
C1
C2
C3
C4
A1
B1
D
T
(g)
WDS No.
162 110 138.8 86.5 42 94.5 147.5 128 73.5 5.2 1.2
70
8662-202
176 127 151.8 103.8 50 112 161.5 144 93.4 5.2 1.2
80
8662-203
Mounting Plate - To
Suit WDS 8661-
202/203
WDS 8662
MATERIAL
-
Steel Zinc Plated
$
%
&
&
&
&
&
%
$
'
7
7R VXLW
ZP
