SECTION 5 - HAND KNOBS
WDS
WDS
www.wdsltd.co.uk5-33
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukThumb Screw
WDS 8168
MATERIAL
-
Thermoplastic, black
Screw- Steel, zinc plated
D
D1
D2
H
H1
L
(g)
WDS No.
M3
10
8
4.5
0.5
10
7
8168-220
M4
14
8
9
5.5
10
10
8168-224
M4
14
8
9
5.5
15
12
8168-225
M4
14
8
9
5.5
25
14
8168-227
M5
22
12
12
3.5
10
11.5
8168-228
M5
22
12
12
3.5
15
12
8168-229
M6
22
12
12
3.5
15
15
8168-236
M6
22
12
12
3.5
20
16.5
8168-237
M6
22
12
12
3.5
25
17.5
8168-238
M6
22
12
12
3.5
50
25
8168-241
'
'
'
+
+
/
Thumb Nut
WDS 8169
MATERIAL
-
Thermoplastic, black
Insert- Steel, zinc plated
D
D1
D2
H
H1
T
(g)
WDS No.
M6
28
13
15
5
9
12
8169-206
M8
28
13
15
5
12
15
8169-207
'
'
'
+
+
7
Hand Knob -
Female Thread
WDS 8221
MATERIAL
-
Body - Nylon PA6
Insert - Brass
D
D1
D2
D3
H
H1
H2
T
(g)
WDS No.
M4
20
11
7
15
13
4
9.5
4
8221-201
M5
25
13
8
18
15
6.5
8.5
7
8221-203
M5
30
15
8
21
18
6.5
11.5
9
8221-204
M6
30
15
9
21
18
6.5
11.5
10
8221-206
M8
35
17.5
11
24
20
9
11.0
14
8221-208
M10
35
17.5
14
24
20
9
11.0
16
8221-209
'
'
'
'
+
+
7 +
