273 / 816
SECTION 5 - HAND KNOBS
WDS
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk5-34
WDS
www.wdsltd.co.ukHand Screw -
Male Thread
WDS 8222
MATERIAL
-
Body - Nylon PA6
Stem - Steel, Zinc Plated
D
D1
D2
D3
H
H1
L
(g) WDS No.
M4
20
11
7
15
2
20
6 8222-2042020
M5
20
11
8
15
2
25
9 8222-2052520
M6
25
13
10
18
3
28
13 8222-2062825
M6
30
15
10
21
3
28
15 8222-2062830
M8
30
17.5
12
21
3
32
23 8222-2083230
M10
35
17.5
14
24
4
30
33 8222-2103035
'
'
'
'
/
+
+
Mushroom Knob -
Female
WDS 8445
MATERIAL
-
Body - Thermoplastic
Insert - Steel - zinc plated
Insert - Stainless Steel - 303 S31
Black Grey - RAL 7021
D
D1
D2
H
H1
T
(g)
WDS No.
Steel Insert
WDS No.
Stainless
Steel Insert
M4
21
12
21
10
10
8.6
8445-202BG 8445-302BG
M5
21
12
21
10
10
7.8
8445-204BG 8445-304BG
M6
25
14
25
12
10
8.9
8445-206BG 8445-306BG
M8
33
18
33
15
14
22.2 8445-208BG 8445-308BG
'
+
+
7
'
'
ZP
303
RAL
7021
Mushroom Knob -
Female
WDS 8445
MATERIAL
-
Body - Thermoplastic
Insert - Steel - zinc plated
Insert - Stainless Steel - 303 S31
Pale Grey - RAL 7035
D
D1
D2
H
H1
T
(g)
WDS No.
Steel Insert
WDS No.
Stainless
Steel Insert
M4
21
12
21
10
10
8.6
8445-202PG 8445-302PG
M5
21
12
21
10
10
7.8
8445-204PG 8445-304PG
M6
25
14
25
12
10
8.9
8445-206PG 8445-306PG
M8
33
18
33
15
14
22.2
8445-208PG 8445-308PG
'
+
+
7
'
'
ZP
303
RAL
7035
