Rod Holder
WDS 8566
MATERIAL -
Die Cast Zinc
A B C D D1 E (g) WDS No.
8.6 20.3 5.3 15 8.1 3 20 8566-2301
D
D1
A C
E A/F
B
Locking Rod -
Tapered
WDS 8566
MATERIAL -
Zinc Plated Steel
D
L
D L (g) WDS No.
8 600 117 8566-2106
8 1000 195 8566-2110
Locking Rod with
Wheel
WDS 8566
MATERIAL -
Zinc Plated Steel
Polyamide Wheels
D
D1
L
CE
A
C E A D1 D L (g) WDS No.
10 4 15.5 15 8 600 119 8566-2206
10 4 15.5 15 8 1000 199 8566-2210
