www.wdsltd.co.ukRod Support
WDS 8566
MATERIAL
-
Polyamide PA6-GF30
A
B
C
D
H
H1
(g)
WDS No.
22
25
6.3
8
40
29
8566-2414
H
D
A
C
B
H1
Rod Guides
WDS 8566
MATERIAL
-
Polyamide PA6-GF30
A
B
C
D
H
H1
H3
(g)
WDS No.
20
M8
8.2
28
24
33.4
15
12
8566-2424
26
M8
8.2
28
30
39.2
22
15
8566-2430
32
M8
8.2
28
36
47
25
23
8566-2436
A
H
H1
C
B
H2
B
H3
H2
MOUNTING
Gasket Edge - 1.0 by
2.0mm
WDS 8582
MATERIAL
-
PVC
A
B
H
L
WDS No.
0.5-2
6.5
9.5
Per Metre
8582-320
A
B
H
L
