SECTION 1 - GRIPPERS
WDS
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk1-6
WDS
www.wdsltd.co.ukMetric Plain Body
Clamping Pad -
Replaceable
Gripper
WDS 653
MATERIAL
-
Alloy Steel Rc43/46 - Black
Oxide finish
Supplied without Inserts - For
Inserts refer to 698 range
D
D1
H
C
S1
S2
T
(g)
WDS No.
17
10
18
7.5
4
6
M6
3
653-511722
19
12
20
8.5
4
6
M8
5
653-511924
24
16
24
9
4
6
M10
14
653-512428
30
20
26
8.5
4
6
M12
19
653-513030
36
25
32
12
4
6
M12
39
653-513636
A
A
1x45°
H
D
C
D1
S1
S2
20°
SECTION A-A
T
Position of
Replaceable Pad
+0.0
-0.13
0.05
S1 = Stand off on 10mm thick inserts
S2 = Stand off on 12mm thick inserts
Metric Plain Body
Clamping Pad -
Replaceable
Gripper
WDS 653
MATERIAL
-
Alloy Steel Rc43/46 - Black
Oxide finish
Supplied without Inserts - For
Inserts refer to 698 range
D
D1
E
H
L
S1
S2
T
(g)
WDS No.
M10x1.5
10
17
13
15
4
6
3
26
653-5210015
M10x1.5
10
17
13
30
4
6
3
33
653-5210030
M10x1.5
10
17
13
50
4
6
3
42
653-5210050
M12x1.75
12
19
15
20
4
6
5
41
653-5212020
M12x1.75
12
19
15
40
4
6
5
54
653-5212040
M12x1.75
12
19
15
60
4
6
5
67
653-5212060
M16x2.0
16
24
19
25
4
6
6
67
653-5216025
M16x2.0
16
24
19
50
4
6
6
67
653-5216050
M16x2.0
16
24
19
80
4
6
6
67
653-5216080
M20x2.5
20
30
20
30
4
6
8
149 653-5220030
M20x2.5
20
30
20
60
4
6
8
204 653-5220060
M20x2.5
20
30
20
100
4
6
8
281 653-5220100
M24x3.0
25
36
26
40
4
6
10
294 653-5224040
M24x3.0
25
36
26
100
4
6
10
445 653-5224100
C
HEX
A
A
L
H
D
T
HEX
S1
S2
D1
20°
SECTION A-A
Position of
Replaceable Pad
0.05
S1 = Stand off on 10mm thick inserts
S2 = Stand off on 12mm thick inserts
