SECTION 28 - CLAMPS
WDS
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk28-12
WDS
www.wdsltd.co.ukAdjustable Heel
Pin
WDS 809
MATERIAL
-
Stainless Steel
BS 970 Gr 316S11
See 610 Series for this part in
Steel
D
L
D1
D2
L1
L2
L3
R
S
(g)
WDS No.
M5
30
5
2
5
3
2.6
6
8
4.5 809-20530
M5
40
5
2
5
3
2.6
6
8
6 809-20540
M5
50
5
2
5
3
2.6
6
8
7.5 809-20550
M6
30
6
2
8
5
3.2
6
10
6 809-20630
M6
40
6
2
8
5
3.2
6
10
8 809-20640
M6
50
6
2
8
5
3.2
6
10
10 809-20650
M8
40
8
3
12
6
3.7
10
13
13 809-20840
M8
50
8
3
12
6
3.7
10
13
20 809-20850
M8
60
8
3
12
6
3.7
10
13
20 809-20860
M10
60
10
3
16
8
5
16
17
30 809-21060
M10
70
10
3
16
8
5
16
17
40 809-21070
M12
60
12
3
18
9
5.8
20
19
45 809-21260
M12
80
12
3
18
9
5.8
20
19
60 809-21280
/
'
5
'
'
/
/
/
6
316
