sales@wdsltd.co.ukClamping Joint
Clamping Joint
WDS 287
WDS 288
MATERIAL
-
Handle - Glass reinforced
plastic
Clamp parts Aluminium - Nickel
anodized
Screws Steel - Chemical black
finish
MATERIAL
-
Wing grips - Thermoplastic
Clamp parts - Aluminium -
nickel anodized
Screws Steel - blue chromed
D
D1
D2
H
H1
H2
H3
H4
L
C
(g) WDS No.
8
M8
28
72
29
31
13
9
65
8.5
82 287-201
10
M8
32
76
29
35
15
10
65
9.5
100 287-202
12
M8
36
81
29
40
18
11
65
10.5
127 287-203
16
M10
45
103
37.5
50
22
14
80
13.5
233 287-204
D
D1
D2
L
L1
L2
L3
L4
W C
(g) WDS No.
8
M8
28
90
24
42
24
9
50
8.5
86 288-201
10
M8
32
100
24
52
32
10
50
9.5
124 288-202
12
M8
36
104
24
56
34
11
50
10.5
157 288-203
16
M10
45
142
35
72
44
14
75
13.5
345 288-204
/
&
+ +
+
++
'
'
'
/
/
/
&
'
'
'
/
/
:
