SECTION 2 - LOCATION & POSITIONING
WDS
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk2-6
WDS
www.wdsltd.co.ukLocation Pin -
Inch
WDS 504
MATERIAL
-
Steel BS 970 Gr 220M07
Case hardened
Chemical black finish
D
g6
D1
p6
L
L1
(g)
WDS No.
0.313"
0.250"
15.9
8
4
504-51
0.375"
0.250"
15.9
8
6
504-52
0.438"
0.250"
15.9
8
8
504-53
0.500"
0.313"
17.5
8
12
504-54
0.625"
0.375"
20.6
8
18
504-56
0.750"
0.500"
23.8
8
32
504-58
Type B Inch
/
/
/
'J
' S
7\SH %
D
g6
D1
p6
L
L1
(g)
WDS No.
8
6
16
8
6
504-251
10
6
16
8
7
504-252
12
8
18
8
14
504-253
14
8
18
8
14
504-254
15
10
20
8
21
504-255
16
10
20
8
21
504-256
18
10
20
8
25
504-257
20
12
24
8
35
504-258
22
12
24
8
39
504-259
25
12
24
8
43
504-261
Type B Metric
Location Pin -
Metric
WDS 504
MATERIAL
-
Steel BS 970 Gr 220M07
Case hardened
Chemical black finish
/
/
/
'J
' S
7\SH %
