SECTION 3 - HAND LEVERS
WDS
WDS
www.wdsltd.co.uk3-1
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukClamping Handle
Clamping Lever -
Indexing
WDS 8194
WDS 8196
MATERIAL
-
Steel
Chemical black finish with a black
plastic ball knob
MATERIAL
-
Steel Chemical black finish
Black plastic ball knob
D
D1
D2
D3
H
H1
L
T
(g)
WDS No.
M8
24
25
10
52.5
40
84.5
18
82
8194-2508
M10
24
25
10
52.5
40
84.5
19
78
8194-251
M12
28
32
12
61
46
100
20
100 8194-252
M16
33
32
13
72
52
121
23
185 8194-253
After securely tightening in position,
the handle is lifted against the
spring pressure and indexed to a
suitable parking position and
re-engaged with the splined nut
D D1
D2
D3
D4
H H1
H2
L
N
T
Size
(g) WDS No.
M8 24
16
25
10 68.5 49.5 4.5 88
28
14
1
180 8196-211
M10 28
19
32
12 68.5 51.5 5.5 111 30
17
2
260 8196-212
M12 33
23
32
13
81
58
6 134.5 35
23
3
350 8196-213
M16 41
30
32
13 89.5 68.5 7.5 134 38
35
4
680 8196-214
+
/
'
7
+
'
'
'
'
'
'
7
+
+
/
+
r
'
'
1 1R 2) ,1'(; 326,7,216
/,)7 +$1'/( 72 ,1'(;
N = No of indexing positions
