SECTION 7 - LEVELLING FEET
WDS
WDS
www.wdsltd.co.uk7-27
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukStainless Steel,
Plastic 70mm
Base Levelling
Foot - White or
Blue
WDS 778
D
L
D1
H
H1
P
(g)
WDS No.
White Base
WDS No.
Blue Base
M16
100
70
36
26.5
700
286
778-61270W 778-61270B
M16
150
70
36
26.5
700
340
778-61370W 778-61370B
M16
200
70
36.5
26.5
700
416
778-61470W 778-61470B
M20
100
70
36.5
26.5
700
383
778-61570W 778-61570B
M20
150
70
36.5
26.5
700
485
778-61670W 778-61670B
M20
200
70
36.5
26.5
700
586
778-61770W 778-61770B
M24
100
70
36.5
26.5
700
464
778-61870W 778-61870B
M24
200
70
36.5
26.5
700
764
778-61970W 778-61970B
M24
300
70
36.5
26.5
700
1064
778-62070W 778-62070B
304
Base Pad
P = Safe working load in kilograms (for static compressive load only)
Note: Increasing the angle will decrease the maximum static compressive load. Beware of using at high angles on low friction surfaces.
MATERIAL
-
Stem: Stainless steel (304)
Base: Polypropylene with
Rubber Pad (White Base has
Anti-microbial agent)
Supplied complete with nut
Stainless Steel,
Plastic 80mm Base
Levelling Foot -
White or Blue
WDS 778
D
L
D1
H
H1
P
(g)
WDS No.
White Base
WDS No.
Blue Base
M8
50
80
25
17.5
150
108
778-60180W 778-60180B
M8
100
80
25
17.5
150
119
778-60280W 778-60280B
M10
50
80
25.5
17.5
250
116
778-60380W 778-60380B
M10
100
80
25.5
17.5
250
141
778-60480W 778-60480B
M10
150
80
25.5
17.5
250
165
778-60580W 778-60580B
M12
100
80
25.5
17.5
300
170
778-60680W 778-60680B
M12
150
80
25.5
17.5
300
206
778-60780W 778-60780B
M12
200
80
25.5
17.5
300
242
778-60880W 778-60880B
M16
100
80
25.5
17.5
400
241
778-60980W 778-60980B
M16
150
80
25.5
17.5
400
306
778-61080W 778-61080B
M16
200
80
25.5
17.5
400
373
778-61180W 778-61180B
304
Base Pad
P = Safe working load in kilograms (for static compressive load only)
Note: Increasing the angle will decrease the maximum static compressive load. Beware of using at high angles on low friction surfaces.
MATERIAL
-
Stem: Stainless steel (304)
Base: Polypropylene with
Rubber Pad (White Base has
Anti-microbial agent)
Supplied complete with nut
H1
D1
D
L
H
25°
H1
D1
D
L
H
25°
