SECTION 7 - LEVELLING FEET
WDS
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk7-28
WDS
www.wdsltd.co.ukD
L
H
H1
P
(g)
WDS No.
White Base
WDS No.
Blue Base
M8
50
25
17.5
150
115
778-60181W 778-60181B
M8
100
25
17.5
150
131
778-60281W 778-60281B
M10
50
26
17.5
250
128
778-60381W 778-60381B
M10
100
26
17.5
250
153
778-60481W 778-60481B
M10
150
26
17.5
250
177
778-60581W 778-60581B
M12
100
26
17.5
300
182
778-60681W 778-60681B
M12
150
26
17.5
300
218
778-60781W 778-60781B
M12
200
26
17.5
300
254
778-60881W 778-60881B
M16
100
26
17.5
400
253
778-60981W 778-60981B
M16
150
26
17.5
400
318
778-61081W 778-61081B
M16
200
26
17.5
400
385
778-61181W 778-61181B
Stainless Steel,
Extended Bolt
Down Base
Levelling Foot -
White or Blue
WDS 778
304
Base Pad
P = Safe working load in kilograms (for static compressive load only)
Note: Increasing the angle will decrease the maximum static compressive load.
Beware of using at high angles on low friction surfaces.
MATERIAL
-
Stem: Stainless steel (304)
Base: Polypropylene with
Rubber Pad (White Base has
Anti-microbial agent)
Supplied complete with nut
D
L
H
H1
8.5
25°
9
R15
80
65
