SECTION 7 - LEVELLING FEET
WDS
WDS
www.wdsltd.co.uk7-29
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukD
L
D1
D2
C
H
H1
H2
P
(g)
WDS No.
White Base
WDS No.
Blue Base
M8
50
80
9
56
25 17.5 15 150
104 778-60182W 778-60182B
M8 100 80
9
56
25 17.5 15 150
120 778-60282W 778-60282B
M10 50
80
9
56
26 17.5 15 150
117 778-60382W 778-60382B
M10 100 80
9
56
26 17.5 15 250
142 778-60482W 778-60482B
M10 150 80
9
56
26 17.5 15 250
166 778-60582W 778-60582B
M12 100 80
9
56
26 17.5 15 300
171 778-60682W 778-60682B
M12 150 80
9
56
26 17.5 15 300
207 778-60782W 778-60782B
M12 200 80
9
56
26 17.5 15 300
243 778-60882W 778-60882B
M16 100 80
9
56
26 17.5 15 400
242 778-60982W 778-60982B
M16 150 80
9
56
26 17.5 15 400
307 778-61082W 778-61082B
M16 200 80
9
56
26 17.5 15 400
374 778-61182W 778-61182B
M16 100 100 11
75
36
24
21 500
347 778-61202W 778-61202B
M16 150 100 11
75
36
24
21 500
413 778-61302W 778-61302B
M16 200 100 11
75
36
24
21 500
479 778-61402W 778-61402B
M20 100 100 11
75
36
24
21 600
446 778-61502W 778-61502B
M20 150 100 11
75
36
24
21 600
548 778-61602W 778-61602B
M20 200 100 11
75
36
24
21 600
649 778-61702W 778-61702B
M24 100 100 11
75
46
24
21 700
527 778-61802W 778-61802B
M24 200 100 11
75
46
24
21 700
827 778-61902W 778-61902B
M24 300 100 11
75
46
24
21 700
1127 778-62002W 778-62002B
Stainless Steel,
Double Bolt Down
Levelling Foot -
White or Blue
WDS 778
H1
D
L
H
H2
25°
C
D1
D2
304
Base Pad
P = Safe working load in kilograms (for static compressive load only)
Note: Increasing the angle will decrease the maximum static compressive load. Beware of using at high angles on low friction surfaces.
MATERIAL
-
Stem: Stainless steel (304)
Base: Polypropylene with
Rubber Pad (White Base has
Anti-microbial agent)
Supplied complete with nut
