SECTION 8 - HANDLES, LATCHES & CATCHES
WDS
✆
0845 606 66 77
•
www.wdsltd.co.uk•
sales@wdsltd.co.uk8-18
WDS
www.wdsltd.co.ukPolyamide Bridge
Handle with Fittings
WDS 8505
MATERIAL
-
Handle : Polyamide PA6-Glass
Reinforced-Black
Fittings in Steel-Black
P = Load Capacity (kg)
A
L
B
C
D
E
F
H
H1
A
B
C
D
E
F
H
H1
L
P
(g)
WDS No.
100
82
8.5
M5x22
19
19
33
13
122
100
58
8505-201
120
98
10.5
M6x25
23
23
39
15
146
100
87
8505-202
140
114
12
M8x30
27
27
45
16
170
100
161
8505-203
160
130
13.5
M8x35
31
31
52
20
194
100
219
8505-204
180
146
15.5
M10x40
35
35
58
20
218
100
325
8505-205
Polyamide Bridge
Handle with
Stainless Steel
Fittings
WDS 8505
MATERIAL
-
Handle: Polyamide PA6-Glass
Reinforced-Black
Fittings in Stainless Steel (1.4301)
Suitable for wet areas
P = Load Capacity (kg)
A
L
B
C
D
E
F
H
H1
A
B
C
D
E
F
H
H1
L
P
(g)
WDS No.
100
82
8.5
M5x22
19
19
33
13
122
100
58
8505-601
120
98
10.5
M6x25
23
23
39
15
146
100
86
8505-602
140
114
12
M8x30
27
27
45
16
170
100
173
8505-603
160
130
13.5
M8x35
31
31
52
20
194
100
215
8505-604
180
146
15.5
M10x40
35
35
58
20
218
100
324
8505-605
