SECTION 8 - HANDLES, LATCHES & CATCHES
WDS
✆
0845 606 66 77
•
www.wdsltd.co.uk•
sales@wdsltd.co.uk8-20
WDS
www.wdsltd.co.ukBridge Handle
WDS 8536
MATERIAL
-
Aluminium, AlMgSi 0.5
Surface finish- Anodised in
silver colour
Screws and Washers supplied
A
B
D
D1
D2
H
M T
Load Capacity
(kg)
(g)
WDS No.
120 146 10.5
22
24
39
M6
12
100
130
8536-251
140 170
12
25
28
45
M8
15
100
155
8536-252
160 194 13.5
28
32
52
M8
15
100
180
8536-253
'
'
0
7
$
%
'
+
Al
Bridge Handle
WDS 8536
MATERIAL
-
Aluminium, AlMgSi 0.5
Surface finish- Anodised in
black colour
Screws and Washers supplied
'
'
0
7
$
%
'
+
Al
A
B
D
D1
D2
H
M T
Load Capacity
(kg)
(g)
WDS No.
120 146 10.5
22
24
39
M6
12
100
130
8536-201
140 170
12
25
28
45
M8
15
100
155
8536-202
160 194 13.5
28
32
52
M8
15
100
180
8536-203
Bridge Handle
WDS 8536
MATERIAL
-
Aluminium, AlMgSi 0.5
Surface finish- Anodised in
Titanium colour
Screws and Washers supplied
Al
D
D2
M
T
A
B
D1
H
A
B
D
D1
D2
H
M T Load Capacity (kg)
(g)
WDS No.
120 146 10.5 22
24
39
M6
12
100
125
8536-351
140 170 12
25
28
45
M8
15
100
193
8536-352
160 194 13.5 28
32
52
M8
15
100
308
8536-353
See 8545 for Stainless Steel version
