SECTION 8 - HANDLES, LATCHES & CATCHES
WDS
✆
0845 606 66 77
•
www.wdsltd.co.uk•
sales@wdsltd.co.uk8-32
WDS
www.wdsltd.co.ukA
B
C
D
E
H
L
T
P
(g)
WDS No.
180
36
200
M8
20
65
39.5
12
100
255
8599-251
230
36
250
M8
20
65
39.5
12
100
295
8599-252
280
36
300
M8
20
65
39.5
12
100
334
8599-253
380
36
400
M8
20
65
39.5
12
100
414
8599-254
480
36
500
M8
20
65
39.5
12
100
493
8599-255
Natural Aluminium
Tube Handle
WDS 8599
MATERIAL
-
Tube: Aluminium AlMgSi 0.5
Legs: Polyamide reinforced, threaded
bush in Brass
Finish
Tube - Natural Anodised
Legs - Black RAL 9005
P = Load Rating (kg)
A
H
H1
E
D
T
B
C
L
A
B
C
D
E
F
H Load kg
(g)
WDS No.
600
380
105
44
40
26
76
80
100
1897 8592-201
700
480
105
44
40
26
76
80
100
2120 8592-202
800
500
145
44
40
26
76
80
100
2180 8592-203
900
600
145
44
40
26
76
80
100
2400 8592-204
1000
700
145
44
40
26
76
80
100
2577 8592-205
Large Stainless
Steel Tube Handles
WDS 8592
MATERIAL
-
Tube: Stainless Steel 1.4301 (Bright)
Base: Die Cast Aluminium (Black)
End Cap: GRP (Black)
Screws: Steel, Zinc plated
E
D
A
B
C
C
L
F
F
H
Al
