SECTION 8 - HANDLES, LATCHES & CATCHES
WDS
✆
0845 606 66 77
•
www.wdsltd.co.uk•
sales@wdsltd.co.uk8-34
WDS
www.wdsltd.co.ukA
B
C
D
E
F
G
H
H1
T
P
(g)
WDS No.
170 16 200 M8
30 72.5 35 67.5 44
15 100
509
8585-251
270 16 300 M8
30 72.5 35 67.5 44
15 100
657
8585-252
370 16 400 M8
30 72.5 35 67.5 44
15 100
778
8585-253
470 16 500 M8
30 72.5 35 67.5 44
15 100
913
8585-254
Machine Handle
WDS 8585
MATERIAL
-
Tube: Aluminium AlMgSi 0.5
Legs: Aluminium AlMgSi 0.5
Extrusion
Finish
Tube - Natural Anodised
Legs - Black
P = Load Rating (kg)
Hexagon Screws M8x16 supplied
Washers supplied
T
A
E
H
H1
C
D
B
G
A
B
C
D
E
F
G
H
H1
T
P
(g)
WDS No.
170 16 200 M8
30 72.5 35 67.5 44
15 100
509
8585-201
270 16 300 M8
30 72.5 35 67.5 44
15 100
657
8585-202
370 16 400 M8
30 72.5 35 67.5 44
15 100
778
8585-203
470 16 500 M8
30 72.5 35 67.5 44
15 100
913
8585-204
Machine Handle
WDS 8585
MATERIAL
-
Tube: Aluminium AlMgSi 0.5
Legs: Aluminium AlMgSi 0.5
Extrusion
Finish
Tube - Black Anodised
Legs - Black
P = Load Rating (kg)
Hexagon Screws M8x16 supplied
Washers supplied
T
A
E
H
H1
C
D
B
G
Al
Al
