SECTION 8 - HANDLES, LATCHES & CATCHES
WDS
✆
0845 606 66 77
•
www.wdsltd.co.uk•
sales@wdsltd.co.uk8-36
WDS
www.wdsltd.co.ukTube Handle -
Front Mounted
WDS 8538
MATERIAL
-
Sides - Glass Reinforced Polyamide
PA6
Colour - black RAL 9005
Grip - aluminium round AlMgSi 0.5
Colour - matt anodized
Black cheesehead screws M
supplied with washers and nuts
L
L1 L2 L3 L4 D D1 H H1 W M
Load Capacity
(kg)
(g)
WDS No.
200 50 70 105 15 20 27 42 16 30 M8x30
80
370 8538-201
250 50 70 105 15 20 27 42 16 30 M8x30
80
414 8538-202
300 50 70 105 15 20 27 42 16 30 M8x30
80
457 8538-203
350 50 70 105 15 20 27 42 16 30 M8x30
80
501 8538-204
400 50 70 105 15 20 27 42 16 30 M8x30
80
544 8538-205
:
'
'
/
/
+
+
/
/
/
0
:
'
'
/
/
+
+
/
/
/
0
Strap Handle
WDS 8530
MATERIAL
-
Rubber Strap Matt Black
Electro polished Steel End-Plates
L
L2
W
Load Capacity (kg)
(g)
WDS No.
195
165
13
30
66
8530-201
210
185
22
30
69
8530-202
/
/
:
Suitable for M4 Countersunk Screws
Al
