SECTION 8 - HANDLES, LATCHES & CATCHES
WDS
✆
0845 606 66 77
•
www.wdsltd.co.uk•
sales@wdsltd.co.uk8-42
WDS
www.wdsltd.co.ukA
B
C
D
E
F
G
H
J
T
P
(g)
WDS No.
170 16 200 M8
30 72.5 35 72.5 25
15 100
555
8584-251
270 16 300 M8
30 72.5 35 72.5 25
15 100
690
8584-252
370 16 400 M8
30 72.5 35 72.5 25
15 100
824
8584-253
470 16 500 M8
30 72.5 35 72.5 25
15 100
959
8584-254
Machine Handle
WDS 8584
MATERIAL
-
Tube: Aluminium AlMgSi 0.5
Legs: Aluminium AlMgSi 0.5
Extrusion
Finish
Tube - Natural Anodised
Legs - Black
Galvanised Hexagon Screws M8 x 16
and Washers supplied
P = Load Rating (kg)
A
E
F
B
G
H
J
T
C
D
A
B
C
D
E
F
G
H
J
T
P
(g)
WDS No.
170 16 200 M8
30 72.5 35 72.5 25
15 100
555
8584-201
270 16 300 M8
30 72.5 35 72.5 25
15 100
690
8584-202
370 16 400 M8
30 72.5 35 72.5 25
15 100
824
8584-203
470 16 500 M8
30 72.5 35 72.5 25
15 100
959
8584-204
Machine Handle
WDS 8584
MATERIAL
-
Tube: Aluminium AlMgSi 0.5
Legs: Aluminium AlMgSi 0.5
Extrusion
Finish
Tube - Black Anodised
Legs - Black
Galvanised Hexagon Screws M8 x
16 and Washers supplied
P = Load Rating (kg)
A
E
F
B
G
H
J
T
C
D
Al
Al
