SECTION 8 - HANDLES, LATCHES & CATCHES
WDS
WDS
www.wdsltd.co.uk8-45
✆
0845 606 66 77
•
www.wdsltd.co.uk•
sales@wdsltd.co.ukA
B
C
D
D1
E
H
T
P
(g)
WDS No.
135
22
150
M6
30
15
45
9
80
112
8598-201
185
22
200
M6
30
15
45
9
80
130
8598-202
235
22
250
M6
30
15
45
9
80
148
8598-203
285
22
300
M6
30
15
45
9
80
165
8598-204
335
22
350
M6
30
15
45
9
80
184
8598-205
385
22
400
M6
30
15
45
9
80
201
8598-206
Aluminium Tube
Handle with Black
Legs
WDS 8598
MATERIAL
-
Tube: Aluminium AlMgSi 0.5
Legs: Polyamide reinforced, threaded
bush in Brass
Finish
Tube - Natural Anodised
Legs - Black
P = Load Capacity (kg)
H
B
A
E
C
D1
T
D
A
B
C
D
E
F
G
H
L
T
P
(g)
WDS No.
88
80
12
M4
12
12
17
33
100
12
20
28
8594-201
96
88
12
M4
12
12
17
33
108
12
20
30
8594-202
120
112
12
M4
12
12
17
33
132
12
20
31
8594-203
128
120
12
M4
12
12
17
33
140
12
20
33
8594-204
160
152
12
M4
12
12
17
33
172
12
20
35
8594-205
180
172
12
M4
12
12
17
33
192
12
20
37
8594-206
Aluminium Tube
Handles - Black
Anodised
WDS 8594
MATERIAL
-
Legs : Polyamide PA6 - Glass
Reinforced-Black
Thread Insert: Brass
Grip: Aluminium AlMgSi 0.5 Black
Anodised
P = Load Capacity (kg)
A
L
B
C
E
F
G
H
D
T
Al
Al
