SECTION 8 - HANDLES, LATCHES & CATCHES
WDS
WDS
www.wdsltd.co.uk8-43
✆
0845 606 66 77
•
www.wdsltd.co.uk•
sales@wdsltd.co.ukA
B
C
D
E
F
G
H
J
T
P
(g)
WDS No.
184 10 200 M8
16 72.5 33 77.5 54
15 100
479
8586-201
284 10 300 M8
16 72.5 33 77.5 54
15 100
614
8586-202
384 10 400 M8
16 72.5 33 77.5 54
15 100
748
8586-203
484 10 500 M8
16 72.5 33 77.5 54
15 100
882
8586-204
Machine Handle
WDS 8586
MATERIAL
-
Tube: Aluminium AlMgSi 0.5
Legs: Aluminium AlMgSi 0.5
Extrusion
Finish
Tube - Black Anodised
Legs - Black
Galvanised Hexagon Screws M8 x 16
and Washers supplied
P = Load Rating (kg)
C
A
H
H1
E
D
F
G
B
T
A
B
C
D
E
F
G
H
J
T
P
(g)
WDS No.
184 10 200 M8
16 72.5 33 77.5 54
15 100
479
8586-251
284 10 300 M8
16 72.5 33 77.5 54
15 100
614
8586-252
384 10 400 M8
16 72.5 33 77.5 54
15 100
748
8586-253
484 10 500 M8
16 72.5 33 77.5 54
15 100
882
8586-254
Machine Handle
WDS 8586
MATERIAL
-
Tube: Aluminium AlMgSi 0.5
Legs: Aluminium AlMgSi 0.5
Extrusion
Finish
Tube - Natural Anodised
Legs - Black
Galvanised Hexagon Screws M8 x 16
and Washers supplied
P = Load Rating (kg)
C
A
H
H1
E
D
F
G
B
T
Al
Al
