SECTION 9 - HINGES
WDS
WDS
www.wdsltd.co.uk9-5
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukA
B
C
D
E
F
H
H1
L
T
(g)
WDS No.
33
15.5
42
5
6.5
6
20
16
60
2.2
76
8676-601
Hinge - Lift Off
Concealed -
Stainless Steel
WDS 8676
MATERIAL
-
Body: Stainless Steel
Pin: Stainless Steel
L
E
D
C
F
A
B
T
H
H1
Hinge - Lift Off
Concealed - Steel
WDS 8607
MATERIAL
-
Hinge - Steel Zinc Plated
Pin - Steel Zinc Plated
Door Part not coated - weldable
Concealed Hinge for surface
mounted doors
Opening Angle = 120°
Countersunk holes to suit M5 screws
Removable Pin for Detachable Doors
/
/
/
&
&
'
%
(
)
7
%
%
/
'
B B1 B2 C C1 D D1 E F L L1 L2 L3 T Opening
Angle
(g) WDS No.
16 5.3 6 53 7 5 5.4 15 20 60 36 67 78 2.5 120°
105 8607-201
ZP
Hinge - Lift Off
Concealed -
Stainless Steel
WDS 8607
MATERIAL
-
Hinge - 304 Stainless Steel
Pin - 304 Stainless Steel
Concealed Hinge for surface mounted
doors
Opening Angle = 120°
Countersunk holes to suit M5 screws
Removable pin for detachable doors.
/
/
/
&
&
'
%
(
)
7
%
%
/
'
B B1 B2 C C1 D D1 E F L L1 L2 L3 T Opening
Angle
(g) WDS No.
16 5.3 6 53 7 5 5.4 15 20 60 36 67 78 2.5 120°
98 8607-601
304
