SECTION 9 - HINGES
WDS
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk9-6
WDS
www.wdsltd.co.ukHinge - Lift Off
Concealed - Zinc
Plated Steel
MATERIAL
-
Body: Mild Steel-Zinc plated
Pin: Mild steel
L
L1
C
C1
B
D
A
E
H
T
F
WDS 8678
A
B
C
C1
D
E
F
H
L
L1
T
(g)
WDS No.
20
12
48
42
6
6.5
32
18
60
73
2.5
89
8678-201
Hinge - Lift Off
- Concealed -
Stainless Steel
MATERIAL
-
Body: Stainless Steel
Pin: Stainless Steel
WDS 8678
A
B
C
C1
D
E
F
H
L
L1
T
(g)
WDS No.
20
12
48
42
6
6.5
32
18
60
73
2.5
89
8678-601
L
L1
C
C1
B
D
A
E
H
T
F
Hinge - Lift Off Con-
cealed - Zinc Plated
Steel
WDS 8608
MATERIAL
-
Hinge - Steel Zinc Plated
Pin - Steel Zinc Plated
Door Part not coated - weldable
Concealed Hinge (Heavy Duty)
for surface mounted doors
Opening Angle = 120°
Countersunk holes to suit M6 screw
Removeable Pin for Detachable Doors
B B1 B2 C D D1 E E1 F
L
L1 L3 T Opening
Angle
(g) WDS No.
27.8 2.8 12.4 25 6 6.3 22 6 23 90 48 109 2.8 120°
155 8608-201
&
/
/
/
'
%
%
%
(
)
7 (
'
ZP
Note: Door part plated, with holes for fixings
Note: Door part weldable or with holes for fixings
ZP
304
