SECTION 9 - HINGES
WDS
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk9-12
WDS
www.wdsltd.co.ukHinge - Surface
Mount - Stainless
Steel
WDS 8625
MATERIAL
-
316 Stainless steel
Pin - Steel Zinc Plated
H1 H D2 D1 D C2 C1 C B A L Fa Fr
Finish
(g) WDS No.
4
7.5
3
4.2
8
9
9
18
15
15
30
30 55 Polished 38 8625-200
5
9
4
5.2
10 12.5 12.5 25
20
20
40
70
120 Polished 55 8625-201
6
11.5
6
6.2
12
15
15
30
25
25
50
90
160 Polished 120 8625-203
6
11.5
6
6.5
12
28
15
30
38
25
50
50
160 Polished 125 8625-204
6
11.5
6
6.5
12
28
28
30
38
38
50
50
160 Polished 155 8625-2045
8
15
8
8.3
16
18
18
36
30
30
60
110 180 Polished 220 8625-205
4
7.5
3
4.2
8
9
9
18
15
15
30
30 550 Matt
38 8625-200M
5
9
4
5.2
10 12.5 12.5 25
20
20
40
70
120 Matt
55 8625-201M
6
11.5
6
6.2
12
15
15
30
25
25
50
90
160 Matt
120 8625-203M
6
11.5
6
6.5
12
28
15
30
38
25
50
50 160 Matt
125 8625-204M
6
11.5
6
6.5
12
28
28
30
38
38
50
50
160 Matt
155 8625-2045M
8
15
8
8.3
16
18
18
36
30
30
60
110 180z Matt
220 8625-205M
C1 C2
C
L
A
B
270°
D2
D
H
H1
D1
316
Hinge - Surface
Mount - Zinc Die
Cast
WDS 8630
MATERIAL
-
Leaves - Zinc Die Cast Black Finish
Hinge Pin - Stainless Steel (304)
A B C C1 C2 D D2 H H1 L Angle Max Radial Load
(kg) @ 180°
Max Radial Load
(kg) @ 90°
Max Axial
Load (kg)
(g) WDS No.
20 20 25 12.5 12.5 4 5.3 9 5 40 270
210
200
115
45 8630-201
25 25 30 15 15 6 6.3 11.5 6 50 270
350
245
210
105 8630-203
38 25 30 28 15 6 6.3 11.5 6 50 270
300
125
150
105 8630-204
38 38 30 28 28 6 6.3 11.5 6 50 270
300
125
130
130 8630-2045
30 30 36 18 18 8 8.3 15 8 60 270
600
440
320
225 8630-205
60 30 36 18 45 8 8.3 15 8 60 180
450
150
150
230 8630-207
60 60 36 45 45 8 8.3 15 8 60 180
450
150
130
295 8630-209
H
H1
D
A B
L
D2
C
C1 C2
30
270°
180°
8630-2045
ONLY
