SECTION 9 - HINGES
WDS
WDS
www.wdsltd.co.uk9-17
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukHinge - Concealed -
Zinc Die Cast
WDS 8642
MATERIAL
-
Frame Part - Zinc Die Cast
Door Part - Steel Copper Plated
Supplied with M5 Screws (2 off)
Drive Fit Pin for Final Assembly
Concealed Hinge for surface
mounted doors
Opening Angle - 130°
A
B
C
D
E
F
G
L
(g)
WDS No.
19
17.5
36
M5
7.3
11.5
12.5
57
85 8642-202
&
/
'
(
%
)
$
*
Hinge - Concealed -
Steel
WDS 8643
MATERIAL
-
Frame Part - Steel, Zinc Plated
Door Part - Steel Copper Plated
Supplied with M5 Screws (2 off)
Drive Fit Pin for Final Assembly
Concealed Hinge for surface
mounted doors
Opening Angle - 110°
A
B
C
D
E
F
L
(g)
WDS No.
19
14.5
36
M5
7.3
11.3
56
70
8643-202
'
/
&
(
%
$
)
ZP
Hinge - Concealed -
Steel
WDS 8644
MATERIAL
-
Frame Part - Steel, Zinc Plated
Door Part - Steel Copper Plated
Drive Fit Pin for Final Assembly
Concealed Hinge for surface mounted
doors
Opening Angle - 110°
Note: M5 Screws not supplied
A B C C1 D D1 D2 E
F
G
H
L
L1
(g) WDS No.
23.5 17.75 36 68 M5 5
6 15 11 7.5
2
80
54
95 8644-202
F
C1
D1
L1
E
B
A
H
D2
L
C
G
ZP
