sales@wdsltd.co.ukHinge - Surface
Mount - Polyamide
WDS 8656
MATERIAL
-
Leaves - Polyamide
Hinge Pin - Stainless Steel
Bushes - Brass
Female Threaded Bushes
A
B
C
D
T
F
H
Fa (kg)
Fr (kg)
(g) WDS No.
50
46
11
M5
7.5
30
30
36.7
31.6
45 8656-201
65
63
13.5
M6
7.5
40
40
51.9
49.9
110 8656-203
98
98
20
M10
15
62.5
60
107
209
290 8656-204
&
$
+
)
%
' [ 7 GHHS
Fa = Maximum Recommended Load - Axial
Fr = Maximum Recommended Load - Radial
See Page 9-28 for technical information
Hinge - Surface
Mount - Polyamide
WDS 8657
MATERIAL
-
Leaves - Polyamide
Hinge Pin - Stainless Steel
Stud - Steel Zinc Plated
Male Threaded Studs
A
B
C
D
T
F
H
Fa (kg)
Fr (kg)
(g)
WDS No.
50
46
11
M5
20
30
30
36.7
31.6
50 8657-201
65
63
13.5
M6
15
40
40
51.9
49.9
105 8657-202
98
98
20
M10
20
62.5
60
107
209
335 8657-203
&
'
7
+
$
)
%
Fa = Maximum Recommended Load - Axial
Fr = Maximum Recommended Load - Radial
