SECTION 9 - HINGES
WDS
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk9-20
WDS
www.wdsltd.co.ukHinge - Spring
Release - Steel
WDS 8651
MATERIAL
-
Door Part - Steel Copper Plated
Pin - Steel Zinc Plated
Spring Loaded Pin for Detachable
Doors
A
B
C
D1
D2
D3
D4
E
(g)
WDS No.
47
6
14.5
15
13
9
4
20
70
8651-201
$ % &
'
'
'
(
'
Hinge - Lift Off
Spring Release -
Steel
WDS 8659
MATERIAL
-
Housing - Steel Zinc plated
Pin - Steel Zinc plated
Spring - Steel Zinc plated
Spring Loaded Pin for detachable
doors
With Mounting Holes
A B C D D1 E
F
G H T
L Supplied As
(g)
WDS No.
26.4 62.5 14.4 6 5.3 6 10 7.25 48 2 89 Left Hand
50
8659-203
26.4 62.5 14.4 6 5.3 6 10 7.25 48 2 89 Right Hand 50
8659-204
D1
B
H G
E
A
D
C
L
T
F
LEFT HAND RIGHT HAND
Hinge - Lift Off
Spring Release -
Steel
WDS 8659
MATERIAL
-
Housing - 304 Stainless Steel
Pin - 304 Stainless Steel
Spring - 304 Stainless Steel
Spring Loaded Pin for detachable
doors
With Mounting Holes
A B C D D1 E
F
G H T
L Supplied As
(g)
WDS No.
26.4 62.5 14.4 6 5.3 6 10 7.25 48 2 89 Left Hand
50
8659-603
26.4 62.5 14.4 6 5.3 6 10 7.25 48 2 89 Right Hand 50
8659-604
D1
B
H G
E
A
D
C
L
T
F
LEFT HAND RIGHT HAND
ZP
304
