Hinge - Split Leaf
Lift Off - Zinc Die
Cast
WDS 8667
MATERIAL
-
Body: Zinc Die Cast - Black
Pin: Steel-Zinc plated
B
H
D2
H1
L
F
G
J
K
A
C
E
K
M
G
J
D
D1
N
P
Hinge - Surface
Mount - Polyamide
MATERIAL
-
Body: Polyamide
Pin: Zinc Plated Mild Steel
A B C C1 D D1 E E1 F
G H H1 J
K
(g)
WDS No.
60.5 94.5 30
10
5.2
6
22
25
7
5
18
9
42
25
72
8666-201
H1
C
B
D1
H
C1
F
J
K
G
E
E1
D
A
WDS 8666
A B
C C1 C2 D E F G H J L L1 L2 M N S T
(g)
WDS No.
25 45 15 15 22 M5 33 18 13
5
4
37 22
6
24 21
9 1.5
8
8668-201
Hinge - Low Profile -
Zinc Die Cast
WDS 8668
MATERIAL
-
Body: Zinc Die Cast-Black Finish
Pin & Plate: Mild Steel, Zinc Plated
E
A
B
C2 C1 C
F
D
H
G
T
J
L
L2 L1
N
M
S
Note: Separate Mounting Plate allows one
leaf to be removed facilitating door lift off.
Mounting Plate attaches to door with 4x
Counter Sunk Fixings. 4x bosses can be
drilled/tapped for M5. Slotted holes in leaf
allow lateral door positioning.
