SECTION 9 - HINGES WDS
& 0845 606 66 77 • : • * 9-28
WDS
Hinge Continuous
WDS 8650
MATERIAL -
Mild Steel or
304 Stainless Steel
W L L1 T P (g)
WDS No.
Mild Steel
WDS No.
Stainless Steel
25.4 1829 12.7 0.9 2.3 0.51 8650-203 8650-603
31.8 1829 12.7 0.9 2.3 0.59 8650-205 8650-605
38.1 1829 12.7 0.9 2.3 0.68 8650-207 8650-607
38.1 1829 25.4 1.5 3.2 1.10 8650-209 8650-609
50.8 1829 25.4 1.5 3.2 1.38 8650-211 8650-611
76.2 1829 25.4 1.5 4.75 2.05 8650-213 8650-613
50.8 1829 25.4 2.0 4.75 2.00 8650-215 8650-615
3
7
/
:
/
304
7ZR VDPH KDQG
DOORZV GRRU WR EH
OLIWHG RII
7ZR RSSRVLWH KDQG
VHFXUHV GRRU
)RUFH 5DGLDO
)U
5LJKW +DQG /HIW +DQG
)RUFH $[LDO
)D
)RUFH GHWDLOV IRU EODFN JODVV
UHLQIRUFHG SODVWLF KLQJHV
Technical Information
