SECTION 10 - QUARTER TURN LOCKS & CATCHES
WDS
WDS
www.wdsltd.co.uk10-1
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk'
+ +
0
+ROH 'HWDLO
'
+ +
0
+ROH 'HWDLO
20.1
+
-
0.1
0.1
22.5
+0.5
0
H1
H
D
M22
20
PIN DRIVE
Hole Detail
SQUARE DRIVE
TRI DRIVE
Quarter Turn -
Polyamide
Cylinder with Key
Quarter Turn
Chrome Finish with
Key
Quarter Turn
Polyamide
WDS 8559
WDS 8564
WDS 8562
MATERIAL -
Housing - Polyamide
Key Code 1333 Standard.
Other codes available to order
Suitable for use with Cams - 8575
(Non Limiter Type)
MATERIAL -
Housing - Zinc Die Cast
Key Code 1333 Standard.
Other codes available to order.
Suitable for use with Cams - 8575
(Non Limiter Type)
MATERIAL -
Housing - Polyamide, Zinc Die Cast
Driver
See 8580 for drive keys. IP65 Rated
Suitable for use with Cams - 8575
(Non Limiter Type)
D
H
H1
(g)
WDS No.
28
18
7.5
55
8559-201
D
H
H1
Key Type
(g)
WDS No.
28
18
7.5
3mm Pin Drive
35
8562-201
28
18
7.5
8mm Square Drive
25
8562-203
28
18
7.5
9mm Tri Drive
40
8562-205
D
H
H1
Finish
(g)
WDS No.
28
18
7.5
Chrome
85
8564-201
