SECTION 9 - HINGES
WDS
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk9-26
WDS
www.wdsltd.co.ukHinge - Low Profile -
Zinc Die Cast
MATERIAL
-
Body - Zinc die cast
Thread - Mild Steel - Zinc plated
Pin - Mild Steel Zinc plated
Plates - Mild Steel Zinc plated
L A B B1 C C1 C2 D D1 D2 D3 E F G H H1 J K L1 M T
(g) WDS No.
72 8.5 33 29 34 22 19.5 2.5 M5 9 5 24 21 6 4 4 14 2 16 1.5 9
83 8669-201
L
C2
B
B1
A C
C1
H1
T
D1
L1
H
D
E
F
G C1
D2
J
C2
D3
KM
K
WDS 8669
A
B
C
C1
D
D1
H
H1
(g)
WDS No.
50
70
30
40
6
6.5
6
3
107
8673-201
Hinge - Surface
Mount Butt - Zinc
Plated Steel
WDS 8673
MATERIAL
-
Leaves: Mild Steel-Zinc plated
Pin: Mild steel
H
H1
D
B
C1
C
A
D1
Hinge - Surface
Mount Butt -
Stainless Steel
MATERIAL
-
Leaves: Stainless Steel 304
Pin: Stainless Steel 304
H
H1
D
B
C1
C
A
D1
WDS 8673
A
B
C
C1
D
D1
H
H1
(g)
WDS No.
50
70
30
40
6
6.5
6
3
107
8673-601
304
ZP
