SECTION 13 - BALL TRANSFER UNITS WDS
& 0845 606 66 77 • : • * 13-6
WDS
Ball Transfer Unit
- Light Duty, with
Clip
WDS 569
MATERIAL -
Body - Carbon Steel - Zinc
Plated or 304 Stainless Steel
Ball - Steel 9Cr18Mo or 402
Stainless Steel
D D1 D2 H H1 H2 Fixing Hole
+1.0/+1.5
Load Capacity
(kg) (g)
WDS No.
Steel
WDS No.
Stainless Steel
15.88 32 24.5 21.0 10.0 4 24 17 50 569-215 569-615
22.22 45 35.8 27.7 9.0 3 36 50 126 569-222 569-622
30 4 45 100 320 569-230 569-630
'
'
'
+
+
+
Ball Transfer Unit
- Medium Duty
WDS 570
MATERIAL -
Body - Case Hardened Steel
Housing - Electrophorectic Finish
Ball - Steel 9Cr18Mo or
402 Stainless Steel
Note: No seal fitted to 570-701 or
570-701A
Ball Dia
mm
Body Dia
D
mm
Fitted Height
Y
mm
Ref
B
mm
Flange Dia
F
mm
Load Capacity
kg (g)
WDS No.
Steel Balls
15 24 9.5 11.5 31 50 55 570-701
22 36 9.8 20.7 45 180 210 570-702
30 45 13.8 23.0 55 350 370 570-703
45 62 19.0 34.5 75 600 1030 570-704
%
)
'
<
ZP
Note: When using stainless balls,
reduce load capacity by 33%
Note: When using stainless balls,
reduce load capacity by 33%
Ball Dia
mm
Body Dia
D
mm
Fitted Height
Y
mm
Ref
B
mm
Flange Dia
F
mm
Load Capacity
kg (g)
WDS No.
Stainless
Steel Balls
15 24 9.5 11.5 31 35 55 570-701A
22 36 9.8 20.7 45 126 210 570-702A
30 45 13.8 23.0 55 245 370 570-703A
45 62 19.0 34.5 75 420 1030 570-704A
