SECTION 13 - BALL TRANSFER UNITS
WDS
WDS
www.wdsltd.co.uk13-1
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukBall Transfer
Unit - Surface
Mounting 2 Hole
Fitting
Ball Transfer
Unit - Surface
Mounting 2 Hole
Fitting
Ball Transfer
Unit - Surface
Mounting 4 Hole
Fitting
WDS 566
WDS 567
WDS 566
MATERIAL
-
Body - 304 Stainless Steel or
Carbon Steel - Zinc Plated
Ball - 420 Stainless Steel or
Steel 9Cr18Mo
MATERIAL
-
Body - Carbon Steel - Zinc
Plated or 304 Stainless Steel
Ball - 420 Stainless Steel or
Steel 9Cr18Mo
MATERIAL
-
Body - Carbon Steel - Zinc
Plated
Ball - Steel 9Cr18Mo
D D1 D2 D3 H H1 H2 L
L1
Static
Load (kg)
Dynamic
Load (kg)
(kg)
WDS No.
Steel
WDS No.
Stainless Steel
15.88 27.8 33 4.2 20.7 16 0.6 50 40
15
20
40 566-215 566-615
25.4 42 50 5.5 30.8 24 1.2 69 56
25
30
145 566-225 566-625
D D1 D2 D3 H H1 H2 L1
Static Load
(kg)
Dynamic
Load (kg)
(kg)
WDS No.
Steel
WDS No.
Stainless Steel
25.4 71 40 5.5 30 13 3 55.5 45
55
146
567-225 567-625
31.8 74 46 5.5 36 16.2 4.2 60.0 60
70
257
567-232 567-632
D
D1
D2
H
H1
H2
L
C
Static Load
(kg)
Dynamic
Load (kg)
(kg)
WDS No.
38.1 65
6.7
46
33
3.4
77
62
90
110
480
566-438
+
+
'
+
'
'
/
'
/
/
'
'
'
'
+
+
+
'
+
+
'
+
/ VTXDUH
& VTXDUH
'
304
ZP
ZP
304
ZP
Note: When using stainless balls,
reduce load capacity by 33%
Note: When using stainless balls,
reduce load capacity by 33%
