SECTION 12 - ANTI-VIBRATION MOUNTS
WDS
WDS
www.wdsltd.co.uk12-9
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukSandwich Bolt
Down Anti Vibration
Mount
WDS 720
MATERIAL
-
Galvanised plates with Vulcanized
Natural Rubber
A
H
C
D
E
B
A B C D E H Shore Deflection Pressure
(kg)
Shear
Spring Constant
(g)
WDS No.
127 57 5 108 11 43 65
4.5
830
175
12.5
749 720-21065
168 57 5 146 11 43 65
4.5
1800 290
20.5
1056 720-21565
Anti Vibration
Turret Mount
WDS 721
MATERIAL
-
Mild Steel
Black Natural Rubber
E
B
F
A
C
H
H2
H1
D
G
A B C D E F
G H H1 H2 H1
SHORE
ML MD
(g) WDS No.
81 57 45.8 M8 9 10 29 33.5 20 5.5 20
45
35
8
81 721-20845
81 57 45.8 M8 9 10 29 33.5 20 5.5 20
55
65
8
81 721-20855
81 57 45.8 M8 9 10 29 33.5 20 5.5 20
70
100 8
81 721-20870
96 71 61.5 M10 9 11.5 42.7 46.3 32 5.5 32
45
130 10 189 721-21045
96 71 61.5 M10 9 11.5 42.7 46.3 32 5.5 32
55
225 10 189 721-21055
96 71 61.5 M10 9 11.5 42.7 46.3 32 5.5 32
70
350 10 189 721-21070
ML = Max Load (kg)
MD = Max Deflection (mm)
