SECTION 12 - ANTI-VIBRATION MOUNTS
WDS
WDS
www.wdsltd.co.uk12-5
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukMATERIAL
-
Thread & Plate Material: BZP
Steel
Shock Absorbing Rubber: Natural
Rubber, Black
Hardness: 55 Shore A
Temperature Range
-30°C to + 80°C
D
L
D1
L1
Max
Compressive
Load (kg)
Deflection @ Max
Compressive Load
(mm)
(g)
WDS No.
8
8
M3
4
3.6
1.5
2
714-080855
15
15
M4
4
4.7
1.8
5
714-151555
15
20
M4
6
5.5
1.8
7
714-152055
20
15
M6
6
22.1
1.7
12
714-201555
20
20
M6
6
20.4
2.4
15
714-202055
20
25
M6
6
18.6
3.2
15
714-202555
25
15
M6
6
38.1
1.7
17
714-251555
25
25
M6
6
32.6
3.2
25
714-252555
30
15
M8
8
82.6
1.7
28
714-301555
30
25
M8
8
43.7
2.5
30
714-302555
30
30
M8
8
42.8
3.9
45
714-303055
40
20
M8
8
79
3.2
52
714-402055
40
25
M8
8
77
3.5
58
714-402555
40
30
M8
8
74.9
3.9
62
714-403055
40
40
M8
8
73
5.4
79
714-404055
50
20
M10
10
240
2.4
79
714-502055
50
50
M10
10
119.5
6.9
146
714-505055
60
40
M10
10
128.5
6.8
209
714-604055
75
50
M12
12
334
6.6
340
714-755055
Female Cylindrical
Rubber Stop
WDS 714
'
/
'
/
ZP
