SECTION 12 - ANTI-VIBRATION MOUNTS
WDS
WDS
www.wdsltd.co.uk12-1
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukD L D1 L1 D2 L2
Max
Compressive
Load (kg)
Deflection @ Max
Compressive Load
(mm)
Max Shear
Load (kg)
Deflection @
Max Sheer
Load (mm)
(g)
WDS No.
8 8 M3 8 M3 8
3.8
0.9
1.4
1.8
5
710-080855
10 10 M4 8 M4 8
12
1
1.4
1.9
5
710-101055
10 15 M4 8 M4 8
13
1.4
2.2
3.7
5
710-101555
13 13 M4 8 M4 8
4.5
1.3
1.9
3.1
5
710-131355
15 8 M4 8 M4 8
14.9
1.5
2.3
3.8
6
710-150855
15 10 M4 8 M4 8
10
1.7
4.5
3.5
5
710-151055
15 15 M4 8 M4 8
11
1.8
4.9
3.6
5
710-151555
20 8 M6 18 M6 18
15.5
1.6
4.5
3.7
15
710-200855
20 10 M6 18 M6 18
17.3
1.6
5.5
3.5
16
710-201055
20 15 M6 18 M6 18
22.5
1.7
7.9
33
15
710-201555
20 20 M6 18 M6 18
20.4
2.4
8.2
4.8
20
710-202055
20 25 M6 18 M6 18
24
2
9.8
5.2
25
710-202555
25 15 M6 18 M6 18
35
2.3
13.2
4.2
20
710-251555
25 20 M6 18 M6 18
33.9
2.4
13.7
4.8
30
710-252055
25 25 M6 18 M6 18
31
3.2
13.5
6.3
35
710-252555
25 30 M6 18 M6 18
34
3
13.7
4.8
40
710-253055
30 15 M8 23 M8 23
55
1.7
19.5
3.3
50
710-301555
30 20 M8 23 M8 23
50
2.4
19.5
4.8
50
710-302055
30 25 M8 23 M8 23
44.6
3.2
19.5
6.3
55
710-302555
30 30 M8 23 M8 23
42.8
3.9
19.5
7.8
60
710-303055
30 40 M8 23 M8 23
41
4.2
19.5
7.5
68
710-304055
40 20 M8 23 M8 23
84
2.4
35
4.8
80
710-402055
40 30 M8 23 M8 23
76
3.9
35
7.8
95
710-403055
40 40 M8 23 M8 23
75.2
5.4
35.1
10.8
110
710-404055
50 20 M10 27 M10 27
168
3.2
53
7.8
156
710-502055
50 30 M10 28 M10 28
156
3.9
54
7.8
170
710-503055
50 40 M10 28 M10 28
145
5.4
54.2
10.8
215
710-504055
50 50 M10 28 M10 28
124
6.9
54.2
10.8
240
710-505055
60 40 M10 28 M10 28
176
5.4
54.2
10.8
210
710-604055
75 50 M12 37 M12 37
341
6.5
122
13.2
485
710-755055
Male/Male Thread
Mount
WDS 710
MATERIAL
-
Thread & Plate Material: BZP
Steel
Shock Absorbing Rubber:
Natural Rubber, Black
Hardness: 55 Shore A
Temperature Range
-30°C to + 80°C
'
/
/
/
'
'
ZP
