SECTION 11 - CASTORS & WHEELS WDS
& 0845 606 66 77 • : • * 11-24
WDS
Levelling Castor
WDS 12252
MATERIAL -
Wheel - Polyurethane : 12252-101/102 &
105
Wheel - Polyamide: 12252-103/104 & 106
Frame - Zinc Plated Steel
Bearing - Ball Bearings
To be used wherever machines and
equipment on wheels need to be
brought to a stable standstill.
The castor is fixed by stepping on the
longer lever. By stepping on the
shorter lever, the equipment
becomes movable again. The force
necessary to operate the levers is not
affected by the weight of the load.
D D1 C C1
Maximum
Load kg L L1 R H W (kg) WDS No.
75 9 80 60 300 105 85 150 115-123 40 2 12252-101
125 13 105 80 450 135 110 190 171-181 45 4 12252-102
75 9 80 60 300 105 85 150 115-123 40 2 12252-103
125 13 105 80 450 135 110 190 171-181 45 4 12252-104
80 9 80 60 150 105 85 150 117-123 25 1.8 12252-105
80 9 80 60 200 105 85 150 117-123 30 1.8 12252-106
'
5
&
&
/
/
'
+
:
ZP
Stainless Steel Heavy
Duty Levelling Castor
WDS 12253
MATERIAL -
Wheel - Polyamide
Castor - 304 Stainless Steel
Housing - 304 Stainless Steel
To be used wherever machines and
equipment on wheels need to be brought
to a stable standstill.
The castor is fixed by stepping on the
longer lever. By stepping on the shorter
lever, the equipment becomes movable
again.
The force necessary to operate the levers
is not affected by the weight of the load.
D D1 C C1
Maximum
Load kg L L1 R H W (kg) WDS No.
125 13 105 80 400 140 110 190 160-176 45 3.9 12253-101
D
R.
C1
C
L1
L
D1
H
W
304
