SECTION 11 - CASTORS & WHEELS
WDS
WDS
www.wdsltd.co.uk11-21
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukPlate Fitting Adjustable
Levelling Castor
WDS 12350
MATERIAL
-
Die Cast Aluminium footpad.
Forged Steel top plate, flange and swivel
head.
Die cast aluminium body.
Powder coated black finish.
Spanner operated adjusting nut.
D D1 D2 C L H H1 R R1 W W1
Load kg
Static
Load kg
Dynamic
Wheel
Colour
(kg)
WDS No.
72 11 98 70 95 121 18 80.5 61.5 34 65 1300
650
Black
2.05
12350-255
92 13 100 70 100 130 25 115 57 54 90 1800
900
Blue
5.4
12350-256
5
'
5
+
+
/
'
'
&
:
:
Stem Fitting Adjustable
Levelling Castor
WDS 12197
MATERIAL
-
Die Cast Aluminium footpad with vibration
damping rubber pad.
Forged Steel top plate/flange and swivel
head.
Powder Coated Ivory Finish
Nylon Handwheel with M12 Leveler.
Supplied with Nut and Stud
D D1 D2 D3 H H1 R R1 W W1 A
Load kg
Static
Load kg
Dynamic (kg)
WDS No.
42
M8 40 58 71 10 51 33 20 40 13 50
25
0.3
12197-201
50 M12 46 70 82 10 61 40 25 53 11 250 125 0.6
12197-202
63 M12 65 85 102 15 77.5 47.5 30 64 11 500 250 1.6
12197-203
75 M16 40 58 120 12 52 70 35 57 18 750 375 1.8
12197-204
