SECTION 11 - CASTORS & WHEELS WDS
& 0845 606 66 77 • : • * 11-18
WDS
Top Plate Fitting
Plastic Body Swivel
Castor
WDS 12360
MATERIAL -
Frame: Glass fibre reinforced nylon/
polyamide
Wheel Hub: Polypropylene/PP
Wheel Tyre: Rubber - non marking - 65
shore hardness
Wheel Bearing: Ball
D L L1 C C1 C2 H R R1 D1 W W1 T
Load Capacity
(kg) (kg) WDS No.
102 96 63 78.5 45 71.5 147 87 36.5 8.5 32 57 3.5 136 0.618 12360-100
R1
T
D
H
R
W
W1 C
C2
C1 L1
L
D1
Top Plate Fitting
Plastic Body Swivel
Castor Braked
WDS 12360
MATERIAL -
Frame: Glass fibre reinforced nylon/
polyamide
Wheel Hub: Polypropylene/PP
Wheel Tyre: Rubber - non marking - 65
shore hardness
Wheel Bearing: Ball
D L L1 C C1 C2 H R R1 D1 W W1 T Load Capacity
(kg) (kg) WDS No.
102 96 63 78.5 45 71.5 147 108 36.5 8.5 32 57 3.5 136 0.705 12360-100B
R1
T
D
H
R
W
W1 C
C2
C1 L1
L
D1
Bolt Hole Fitting
Plastic Body Swivel
Castor
WDS 12361
MATERIAL -
Frame: Glass fibre reinforced nylon/
polyamide
Wheel Hub: Polypropylene/PP
Wheel Tyre: Rubber - non marking - 65
shore hardness
Wheel Bearing: Ball
D D1 H R R1 W W1 Load Capacity
(kg) (kg) WDS No.
147 108 36.5 8.5 32 57 3.5 136 0.442 12361-100
R1
D
H
R
W
D1
