SECTION 11 - CASTORS & WHEELS WDS
& 0845 606 66 77 • : • * 11-16
WDS
Top Plate Fitting
Fixed Castor
WDS 12318
MATERIAL -
Wheel - Red Polyurethane Wheel
Coated On Cast Iron Centre
Frame - Steel Zinc Plated
Bearing - Roller
D L L1 C C1 H D1 W
Load
Capacity (Kg) (kg) WDS No.
125 146 107 105 80 159 11 50 300 2 12318-125
152 146 107 105 80 189 11 50 320 2.2 12318-150
200 146 107 105 80 231 11 50 350 2.5 12318-200
Top Plate Fitting
Swivel Castor
WDS 12320
MATERIAL -
Wheel - Red Polyurethane Wheel
Coated On Cast Iron Centre,
Frame -Steel Zinc Plated
Bearing - Roller
D L L1 C C1 H R D1 W
Load
Capacity (Kg) (kg) WDS No.
125 140 110 105 80 159 117.5 11 50 300 2.9 12320-125
152 140 110 105 80 189 133 11 50 320 3 12320-150
200 140 100 105 80 232 162 11 50 350 4 12320-200
' :
+
/
/
&
&
'
'
5
+
:
/ &
&
/
'
Top Plate Fitting
Swivel & Brake Castor
WDS 12322
MATERIAL -
Wheel - Red Polyurethane Wheel
Coated On Cast Iron Centre
Frame - Steel Zinc Plated
Bearing - Roller
D L L1 C C1 H R D1 W
Load
Capacity (Kg) (kg) WDS No.
125 140 110 105 80 159 117.5 11 50 300 2.9 12322-125
152 140 110 105 80 189 133 11 50 320 3.2 12322-150
200 140 110 105 80 232 162 11 50 350 4.3 12322-200
'
5
/
&
/ &
'
:
+
ZP
ZP
ZP
CI
CI
CI
