SECTION 11 - CASTORS & WHEELS WDS
& 0845 606 66 77 • : • * 11-14
WDS
Top Plate Fitting
Fixed Castor
WDS 12170
MATERIAL -
Wheel - Blue Rubber, with
Nylon Centre
Frame - Zinc Plated Pressed Steel
D D1 Maximum Load kg Bearing Type L L1 C C1 H W (kg) WDS No.
100 8.5 200 Roller 105 85 80 60 128 36 0.9 12170-301
125 8.5 250 Roller 105 92 80 60 152 36 1.1 12170-303
160 10.5 300 Ball Journal 134 110 105 80 197 50 1.9 12170-305
'
/
/
&
&
'
:
+
Top Plate Fitting
Swivel Castor
WDS 12170
MATERIAL -
Wheel - Blue Rubber, with
Nylon Centre
Frame - Zinc Plated Pressed Steel
D D1 Maximum Load kg Bearing Type L L1 C C1 H R W (kg) WDS No.
100 8.5 200 Roller 105 83 80 60 128 95 36 1.1 12170-351
125 8.5 250 Roller 105 83 80 60 152 108 36 1.2 12170-353
160 10.5 300 Ball Journal 134 110 105 80 197 130 50 2.3 12170-355
Top Plate Fitting
Swivel & Brake Castor
WDS 12170
MATERIAL -
Wheel - Blue Rubber, with
Nylon Centre
Frame - Zinc Plated Pressed Steel
D D1 Maximum Load kg Bearing Type L L1 C C1 H R W (kg) WDS No.
100 8.5 200 Roller 105 83 80 60 128 115 36 1.3 12170-351B
125 8.5 250 Roller 105 83 80 60 152 115 46 1.4 12170-353B
160 10.5 300 Ball Journal 134 110 105 80 197 148 50 2.8 12170-355B
'
