SECTION 11 - CASTORS & WHEELS WDS
WDS
11-15 & 0845 606 66 77 • : • *
Top Plate Fitting
Fixed Castor
WDS 12355
MATERIAL -
Wheel - Nylon
Frame - Steel Zinc Plated
Bearing - Ball Journal
D L L1 C C1 H D1 W
Load
Capacity (Kg) (kg) WDS No.
100 135 110 105 80 143 11 44 280 1.5 12355-100
125 135 110 105 80 163 11 44 350 1.7 12355-125
150 135 110 105 80 190 11 44 400 1.8 12355-150
'
/
&
/
'
&
:
+
Top Plate Fitting
Swivel Castor
WDS 12356
MATERIAL -
Wheel - Nylon
Frame - Steel Zinc Plated
Bearing - Ball Journal
D L L1 C C1 H R D1 W
Load
Capacity (Kg) (kg) WDS No.
100 135 110 105 80 143 83 11 44 280 1.8 12356-100
125 135 110 105 80 163 100 11 44 350 2 12356-125
150 135 110 105 80 190 110 11 44 400 2.1 12356-150
Top Plate Fitting
Swivel & Brake Castor
WDS 12357
MATERIAL -
Wheel - Nylon
Frame - Steel Zinc Plated
Bearing - Ball Journal
D L L1 C C1 H R D1 W
Load
Capacity (Kg) (kg) WDS No.
100 135 110 105 80 143 83 11 50 280 2 12357-100
125 135 110 105 80 163 100 11 50 350 2.2 12357-125
150 135 110 105 80 190 110 11 50 400 2.4 12357-150
:
+
'
5
/
&
/
'
&
:
+
'
5
/
/ '
&
&
ZP
ZP
ZP
