SECTION 11 - CASTORS & WHEELS
WDS
WDS
www.wdsltd.co.uk11-27
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukPhenolic Resin Wheel
WDS 12188
MATERIAL
-
Wheel - Phenolic Resin
Temperature Range: -40
°
C to +280
°
C
A
B
C
D
E
Maximum Load (kg)
(g)
WDS No.
80
35
40
28
12.2
100
175
12188-201
100
35
40
28
12.2
125
240
12188-203
125
35
40
35
15
150
465
12188-205
160
50
58
35
20.2
250
950
12188-207
Flanged Castor Wheel
WDS 12195
MATERIAL
-
Wheel - 080M40
Shaft - 605M367
Hardened Turned Steel
Note: Threads are fine pitch
Overall
Dia A
Wheel
Dia B
Wheel
Width C
Wheel
Depth D
Bore
Size E
F
Axle
Length G
H J
Load
Capacity (Kg)
(kg) WDS No.
70
55
35
25
12 M16 x 1.5 40 22 10
160
0.7 12195-203
100
85
35
25
20 M24 x 2 52 30 15
370
1.8 12195-205
125
105
35
25
25 M24 x 2 62 32 15
700
2.8 12195-207
(
'
&
%
$
+280ºC
A
B
E
C
D
J G
G
H (hex)
