SECTION 12 - ANTI-VIBRATION MOUNTS
WDS
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk12-4
WDS
www.wdsltd.co.ukD
L
D1
L1
Max
Compressive
Load (kg)
Deflection @ Max
Compressive Load
(mm)
(g)
WDS No.
8
8
M3
8
3.8
0.9
5
713-080855
10
10
M4
8
4.9
1.1
2
713-101055
10
15
M4
8
5.1
1.2
2
713-101555
13
13
M4
8
4.5
1.3
5
713-131355
15
8
M4
8
7.8
1.5
4
713-150855
15
10
M4
8
9.2
1.6
4
713-151055
15
16
M4
8
11
1.8
5
713-151555
20
8
M6
18
14.9
0.8
8
713-200855
20
10
M6
18
24.2
1.4
9
713-201055
20
15
M6
18
22.5
1.7
10
713-201555
20
20
M6
18
20.4
2.4
10
713-202055
20
25
M6
18
18.6
3.2
15
713-202555
25
15
M6
18
38.1
1.7
17
713-251555
25
20
M6
18
33.9
2.4
20
713-252055
25
25
M6
18
31
3.2
25
713-252555
25
30
M6
18
27.8
3.9
26
713-253055
30
15
M8
23
82.6
1.7
33
713-301555
30
20
M8
23
50
2.4
35
713-302055
30
25
M8
23
43.7
3.2
39
713-302555
30
30
M8
23
42.8
3.9
40
713-303055
30
40
M8
23
41.2
3.9
48
713-304055
40
20
M8
23
77
3.9
59
713-402055
40
30
M8
23
76.0
3.9
70
713-403055
40
40
M8
23
75.2
5.4
90
713-404055
50
20
M10
28
240
2.3
85
713-502055
50
40
M10
23
141
5.4
137
713-504055
50
50
M10
28
124
6.9
175
713-505055
60
40
M10
28
176
5.4
205
713-604055
75
50
M12
37
341
6.5
415
713-755055
Male Cylindrical
Rubber Stop
WDS 713
MATERIAL
-
Thread & Plate Material: BZP
Steel
Shock Absorbing Rubber: Natural
Rubber, Black
Hardness: 55 Shore A
Temperature Range
-30°C to + 80°C
'
/
'
/
ZP
