SECTION 12 - ANTI-VIBRATION MOUNTS
WDS
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk12-8
WDS
www.wdsltd.co.ukD A B C E F H H1 Shore Max Load (kg) Static Deflection
(mm)
(g)
WDS No.
M10 46 64 88 108 9 35.5 25 60
60
3.6
250 719-20560
M12 64 84 110 133 11 35.5 20 60
180
3.9
386 719-21560
M16 85 110 136-146 172 14 42 34 60
400
5.6
921 719-22060
Mild Steel Zinc
Plated Anti
Vibration Mounts
WDS 719
MATERIAL
-
Mild Steel Zinc Plated
Black Natural Rubber
Ideal for heavy vibration on
rotating machinery
Suitable for outdoor use
Captive metal parts ideal for use
in transit mounting with inbuilt
fail safe protection
C
F
D
B
H
T
H1
E
A
A B C D E F
H T SHORE MAX LOAD
(kg)
Static
Deflection
(g)
WDS No.
50 63 43 M6 18 7 20 2
40
3.5
2.5
41
718-20540
66 84 52 M8 33 8 25 2
40
20
4.6
82
718-21040
92 112 75 M10 45 10 35 2
40
40
6.4
195
718-21540
Flanged Bolt
Down Anti
Vibration Mount
WDS 718
MATERIAL
-
Mild Steel
Black Natural Rubber
Ideal for light machines at low or
medium vibration
Suitable for outdoor use
A
F
B
C
H
T
E
D
ZP
