SECTION 12 - ANTI-VIBRATION MOUNTS
WDS
WDS
www.wdsltd.co.uk12-3
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukD L D1 L1 D2 L2
Max
Compressive
Load (kg)
Deflection @ Max
Compressive Load
(mm)
Max Shear
Load (kg)
Deflection @
Max Sheer
Load (mm)
(g)
WDS No.
10 15 M4 4 M4 4
5.8
1.3
2.8
2.8
3
712-101555
15 15 M4 4 M4 4
12.1
1.8
5.4
3.6
10
712-151555
20 20 M6 6 M6 6
20.4
2.4
8.2
4.8
15
712-202055
20 25 M6 6 M6 6
25.5
2.4
8.1
6.3
17
712-202555
25 21 M6 6 M6 6
37.3
2.4
15.1
4.8
30
712-252055
25 25 M6 6 M6 6
32.6
3.2
14.2
6.3
30
712-252555
25 30 M6 6 M6 6
27.8
3.9
13.2
7.8
30
712-253055
30 20 M8 8 M8 8
62.5
2.4
24.4
4.8
60
712-302055
30 30 M8 8 M8 8
47.1
3.9
21.4
7.8
60
712-303055
30 40 M8 8 M8 8
40.5
3.9
19.5
7.8
50
712-304055
40 30 M8 8 M8 8
83.4
3.9
38.5
7.8
90
712-403055
40 40 M8 8 M8 8
78.9
5.4
36.8
10.8
105
712-404055
50 40 M10 12 M10 12
118
2.4
51
4.8
145
712-504055
50 50 M10 12 M10 12
124
6.9
54.2
10.8
215
712-505055
60 40 M10 12 M10 12
176
5.4
54.2
10.8
255
712-604055
75 50 M12 15 M12 15
358
6.5
128.1
13.2
445
712-755055
Female/Female
Thread Mount
WDS 712
MATERIAL
-
Thread & Plate Material: BZP
Steel
Shock Absorbing Rubber:
Natural Rubber, Black
Hardness: 55 Shore A
Temperature Range
-30°C to + 80°C
D
L
D1
D2
L2
L1
ZP
