SECTION 14 - GAS STRUTS & END FITTINGS
WDS
WDS
www.wdsltd.co.uk14-3
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukStainless Steel
Gas Strut with
No End Fittings
WDS 850
MATERIAL
-
Body - 316 Stainless Steel
Rod - 316 Stainless Steel
Hardened
Adjusting Valve - Brass
Adjustable Force - Supplied at
maximum force to be adjusted
in position to suit the specific
application.
See also the full range of end
fittings to suit your
application.
L
L1
S
T
S
A
B
T
Pressure releasing
screw in brass end
A
B
L
L1
S
T
Force
Range
Rod Dia
Body Dia
Extended
Shoulder
Length
Stroke
Rod End
Thread
Rod End
Thread
Length
Newtons
(kg)
WDS No.
6
15
172
60
M6x1.0
9
20-400
0.14
850-0615060XX
6
15
252
100
M6x1.0
9
20-400
0.165
850-0615100XX
6
15
352
150
M6x1.0
9
20-400
0.195
850-0615150XX
6
15
452
200
M6x1.0
9
20-400
0.225
850-0615200XX
8
19
252
100
M6x1.0
9
50-700
0.24
850-0819100XX
8
19
352
150
M6x1.0
9
50-700
0.29
850-0819150XX
8
19
452
200
M6x1.0
9
50-700
0.35
850-0819200XX
8
19
552
250
M6x1.0
9
50-700
0.4
850-0819250XX
10
22
457
200
M8x1.25
12
100-1200
0.525
850-1022200XX
10
22
557
250
M8x1.25
12
100-1200
0.6
850-1022250XX
10
22
657
300
M8x1.25
12
100-1200
0.665
850-1022300XX
10
22
857
400
M8x1.25
12
100-1200
0.81
850-1022400XX
14
28
454
200
M10x1.5
14
200-2500
0.89
850-1428200XX
14
28
654
300
M10x1.5
14
200-2500
1.145
850-1428300XX
14
28
854
400
M10x1.5
14
200-2500
1.41
850-1428400XX
14
28
1054
500
M10x1.5
14
200-2500
1.665
850-1428500XX
