SECTION 19 - TOGGLE CLAMPS & ACCESSORIES WDS
& 0845 606 66 77 • : • * 19-36
WDS
Adjustable
Spindle
Neoprene Capped
WDS 859
MATERIAL -
Steel Zinc Plated, Neoprene Cap
'
'
/
/
Washer
WDS 856
MATERIAL -
Steel Zinc Plated
D A B (g) WDS No.
M4 8 1.0 1 856-201
M5 9.4 1.0 1 856-202
M6 12.4 1.4 5 856-204
M8 15.4 2.0 7 856-205
M10 18.9 2.0 10 856-206
M12 24.5 2.8 35 856-207
$
%
'
ZP
ZP
D D1 L L1 (g) WDS No.
M4 10.5 25 13 10 859-202
M6 10.5 44 30 15 859-204
M6 10.5 51 37 20 859-205
M8 11.5 63 43 45 859-206
M10 15 85 60 80 859-208
M12 21.5 100 66.5 125 859-209
