SECTION 24 - SWING BOLTS & FORK ENDS
WDS
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.uk24-12
WDS
www.wdsltd.co.ukSteel Axial Ball
Joints – DIN
71802
WDS 551
MATERIAL
-
Steel Zinc Plated.
EF = Extraction Force
DIN 71802
D
D1
H
H1
L
T
S
EF (Kg)
(g)
WDS No
M5
8
9
10.2
22
10.2
7
3.1
15
551-755
M6
10
11
12.5
25
11.5
8
4.1
25
551-756
M8
13
13
16.5
30
14
11
6.1
55
551-758
M10
16
16
20
35
15.5
13
8.2
104
551-750
M12
16
16
20
35
15.5
13
8.2
104
551-752
S
L
T
D
D1
H1 H
Steel Quick
Release Ball
Joints – SAE J
490
WDS 557
MATERIAL
-
Body, Stem and Sleeve - Steel
Zinc Plated.
Spring - 302S26
SAE J 490 standard
D1
D2
D3
D4
L1
L2
L3
H1
H2
S
(g)
WDS No
6.4
M5
7.9
11.1
23
28
11.1 11.1 11.9
8
17
557-205
7.9
M6
9.4
13
24.6
30
13
12.6 12.6
10
25
557-206
8.6
M8
11.1
16
31.7
40
14.3 15.2 15.2
11
48
557-208
10.7 M10 14.1
19
39.7
49
20
19.8 19.8
13
78
557-210
D3
L1
L2
D1
S
a/f
D2
L3
30°
D4
D2
H2
H1
