SECTION 24 - SWING BOLTS & FORK ENDS
WDS
WDS
www.wdsltd.co.uk24-7
&
0845 606 66 77
•
:
www.wdsltd.co.uk•
*
sales@wdsltd.co.ukE-Clip
WDS 551
MATERIAL
-
Steel Zinc Plated
The clip is used with a clevis
pin to secure the gas spring to
your project.
D
D1
L
(g)
WDS No
4
9.3
0.7
0.16
551-605
5
11.3
0.7
0.26
551-606
6
12.3
0.7
0.28
551-608
8
16.3
1
0.71
551-610
9
18.8
1.1
1.1
551-612
'
'
/
ZP
Angle Joint
WDS 551
MATERIAL
-
Steel Zinc Plated
For use on access hatches and
industrial machinery.
D
D1
H
H1
L
S
T
(g)
WDS No
M5
8
19.2
10.2
22
7
10.2
15
551-705
M6
12.5
23.5
12.5
25
8
11.5
20
551-706
M8
16.5
29.5
16.5
30
11
14
50
551-708
M10
20
36
20
35
13
15.5
104
551-710
M12
16
36
20
35
13
15.5
221
551-712
/
'
7
+
6
+
'
'
ZP
Clevis Pin
WDS 551
MATERIAL
-
Steel Zinc Plated
Pins should be used with an
E-clip DIN6799 to secure the
gas spring to your application.
D
D1
D2
C
H
L
L1
(g)
WDS No
5
4
8
0.74
1.5
13
10.5
2.4
551-505
6
5
9
0.74
1.5
15.5
12.5
4
551-506
8
6
12
0.94
1.5
20
16.5
9
551-508
10
8
14
1.05
2
25
20.5
17
551-510
12
9
17
1.15
3
30
24.5
30
551-512
'
'
/
&
/
+
'
ZP
